PIONEER S-STP501/XTW/E
Manual de Servicio

1

2

3

4

2. EXPLODED VIEWS AND PARTS LIST
A

NOTES : · Parts marked by � NSP � are generally unavailable because they are not in our Master Spare Parts List. · The> mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation.

2.1 PACKING

B

2 7 1 8
C

3 6

D

9

PACKING Parts List
E

Mark No. NSP 1 NSP 1 NSP 2 4 5 6 7 8 9 10 11

Description

Part No.

Mark No. 12 13 14 15

Description Polyethylene Bag S2 Operating Instructions Protector Packing Case

Part No. SHL1420 SRB6086 SHA2532 SHG6303

CS ASSY (Front Speaker) SMW6248 CS ASSY (Surround Speaker) SMW6248 CS ASSY (Center Speaker) Speaker Cable Speaker Cable Speaker Cable Speaker Cable Speaker Cable Non Skid Pad Polyethylene Bag S2 Polyethylene Bag S2 SMW6249 SDS1173 SDS6037 SDS6038 SDS6039 SDS6040 SEP1240 SHL1251 SHL1417

F

2
1 2

S-STP501
3 4
