AUTOMATIC PICTURE QUALITY ADJUSTMENT FUNCTION
When the monitor receives an input signal, it automatically matches the signal to one of the factory preset modes stored in the monitor,s memory to provide a high quality picture at the center of the screen. (See Appendix for a list of the factory preset modes.) For input signals that do not match one of the factory preset modes, the automatic picture quality adjustment function of this monitor automatically adjusts the picture position, phase, and pitch, and ensures that a clear picture appears on the screen for any timing within the monitor,s frequency range (horizontal: 28 - 92 kHz, vertical: 48 - 85 Hz).
Consequently, the first time the monitor receives input signals that do not match one of the factory preset modes, the monitor may take a longer time than normal for displaying the picture on the screen. This adjustment data is automatically stored in memory so that next time, the monitor will function in the same way as when the monitor receives the signals that match one of the factory preset modes. In all modes as above, if the picture is adjusted, the adjustment data is stored as a user mode and automatically recalled whenever the same input signal is received.
Note While the automatic picture quality adjustment function is activated, only the (power) switch will operate.
SDM-S81(E)
5
|
