ADJUSTMENT
1. AM IF Adjustment Settings : � Test point : IC102 (TA2022AFN) Pin22 � Adjustment location : IFT101 ................................... 450kHz 2. AM Tracking Adjustment Settings : � Test point : IC102 (TA2022AFN) Pin22 � Adjustment location : L112 ...................................... 630kHz Waveform max. TC102 .................................. 1440kHz Waveform max. 3. FM IF Adjustment Settings : � Test point : IC102 (TA2022AFN) Pin22 � Adjustment location : TC101 .................................. 10.7MHz
4. FM Frequency Range Adjustment Settings : � Test point : CN101 Pin 20 � Adjustment location : L104 Method : Set to FM 87.5MHz and adjust L104 so that the voltage at the test point becomes 2.3V ± 0.2V. 5. FM Tracking Adjustment Settings : � Test point : IC102 (TA2022AFN) Pin22 � Adjustment location : L102 ....................................... 88MHz Waveform max. 6. FM VCO Frequency Adjustment Settings : � Test point : IC102 (TA2022AFN) Pin17 � Adjustment location : SFR101 .................... 19kHz ± 0.1kHz
� 14 �
|
|
|
> |
|
|
