7. GENERAL INFORMATION
7.1 DIAGNOSIS 7.1.1 DISASSEMBLY
- Removing the Chassis (Fig.1)
Chassis
1
B
Remove the two screws and then remove the Chassis.
1
1
C
Fig.1 - Removing the Main PWB Unit (Fig.2)
2
2 1
1
D
Straighten the tab at location indicated.
2
Remove the four screws and then remove the Main PWB Unit.
2 2
E
Main PWB Unit
Fig.2
F
20 1 2
CD-IB100/XM/E
