PIONEER XW-PSS01-L/WVXJ5
Manual de Servicio

1

2

3

4

2 Diagnosis of the MAIN L ASSY
A

1

Remove 8 screws and detach the Wire Cover L.

3

Detach the Hooks at 2 locations on the Grille L ASSY, and detach the Grille L ASSY.

Wire Cover L

Detach from this side.

1 1 1 1 1

B

1

1 1

Grille L ASSY Hooks

C

Rear View

4 5

Place the Metal Box Unit back to its original inner most position, and detach the Speaker cable from the Hooks (4 locations). Remove the Metal Box Unit from the Outer Base ASSY.

Outer Base ASSY Metal Box Unit

2
D

Place the unit sideway, and if the Metal Box Unit is pushed, the Grille L ASSY and the Metal Box Unit will be pushed out.

5 4 4 4 4

E

2
Metal Box Unit

F

62
1 2

XW-PSS01
3 4
