SONY XSL1230
Manual de Servicio

XS-L830/L1030/L1230
SERVICE MANUAL
REVISED
US Model Canadian Model AEP Model UK Model E Model

Discard the SERVICE MANUAL (No. 9-926-483-11) previously issued.

XS-L1230

SPECIFICATIONS
US/Canadian/AEP/UK model

PARTS LIST
Ref. No. Part No. 1-529-359-11 1-529-359-21 1-529-360-11 1-529-361-11 1-529-484-11 Description Remark SPEAKER (30cm)(XS-L1230:AEP/UK) SPEAKER (30cm)(XS-L1230:E) SPEAKER (25cm)(XS-L1030:AEP/UK/E) SPEAKER (20cm)(XS-L830) SPEAKER (30cm)(XS-L1230:US/Canadian)

E model

1-529-485-11 SPEAKER (25cm)(XS-L1030:US/Canadian) 3-866-444-11 MANUAL, INSTRUCTION (ENGLISH/FRENCH) (US/Canadian) 3-866-444-21 MANUAL, INSTRUCTION (ENGLISH/DUTCH/ SWEDISH/POLISH/GERMAN/PORTUGUESE/ ITALIAN/RUSSIAN/CHINESE) (AEP/UK) 3-866-444-31 MANUAL, INSTRUCTION (ENGLISH/SPANISH/ CHINESE)(E) 1 1 1 2 3 3-024-341-01 3-024-342-01 3-036-242-01 3-397-233-01 3-024-340-01 TEMPLATE (XS-L1230) TEMPLATE (XS-L1030) TEMPLATE (XS-L830) SCREW, TAPPING GASKET

US/Canadian/AEP/UK model

E model

SUBWOOFER

MICROFILM
