SECTION 3 ASSEMBLY OF MECHANISM DECK
Note: Follow the assembly procedure in the numerical order given.
HOUSING
7 Hold the hanger by bending the claw. 5 Fit projection on C part. 1 Install the catch to the hanger. 2 Install the hanger onto two claws of the housing. 4 Fit claw on B part. hanger
3 Put the housing under A part.
6 Fit projection on D part.
housing
C part 8 Hold the hanger by bending the claw.
D part
A part
B part
ARM (SUCTION)
2 Move the arm (suction) in the arrow direction and fit on projection.
projection 1 Fit the arm (suction) on the shaft.
10
|
|
 |
> |
|
|
