Inicio >> CASIO >> W733H-1A Manual de Usuario

 0 artículo(s) en Su carrito

CASIO W733H-1A
Manual de Usuario


¡Twitee acerca de este producto y obtenga $1.00 de crédito en la tienda para uso!
  • Descargable
  • Formato PDF
  • Manual completo
  • Idiomas: English
Precio: $4.99

Descripción del CASIO W733H-1A Manual de Usuario

Manual del propietario completo en formato digital. El manual estará disponible para descarga como archivo PDF después de que lo compre.

El Manual del Propietario (a veces llamado Manual del Usuario o Guía del Usuario) contiene información sobre cómo utilizar su dispositivo. Después de colocar la orden le enviaremos las instrucciones de descarga a su dirección de e-mail.

The manual is available in languages: English

Not yet ready
You must purchase it first

Opiniones de los clientes
No hay comentarios de productos.

TEXT_PDF_SNIPPET
2291-2
STOPWATCH
1/100 second

Alarm Operation
The alarm sounds at the preset time for about 20 seconds, or until you stop it by pressing any button. � The corresponding alarm on indicator flashes in the lower graphic area while the alarm is sounding.

Hours

Seconds

Minutes

The stopwatch lets you measure elapsed time, split times, and two finishes. � The display range of the stopwatch is 199 hours, 59 minutes, 59.99 seconds. � The stopwatch continues to run, restarting from zero after it reaches its limit, until you stop it. � The stopwatch measurement operation continues even if you exit the Stopwatch Mode. � All of the operations in this section are performed in the Stopwatch Mode. See �To switch between the Countdown Timer and Stopwatch� for information about entering the Stopwatch Mode.

To test the alarm In the Alarm Mode, hold down D to sound the alarm.

BACKLIGHT
Auto light switch on indicator

To measure times with the stopwatch
Elapsed Time Start Split Time Start Two Finishes Start Split Stop Split release Clear Split Split release Stop Clear Stop Re-start Stop Clear

The backlight uses an EL (electro-luminescent) panel that causes the entire display to glow for easy reading in the dark. The watch�s auto light switch automatically turns on the backlight when you angle the watch towards your face. � The auto light switch must be turned on (indicated by the auto light switch on indicator) for it to operate. � See �Backlight Precautions� for other important information about using the backlight.

To turn on the backlight manually In any mode, press L to illuminate the display for about two seconds. � The above operation turns on the backlight regardless of the current auto light switch setting.

First runner finishes. Display time of first runner.

Second runner finishes.

Display time of second runner.

About the Auto Light Switch
Turning on the auto light switch causes the backlight to turn on for about two seconds, whenever you position your wrist as described below in any mode. � Be sure to wear the watch on the outside of your left wrist while using the auto light switch. Moving the watch to a position that is parallel to the ground and then tilting it towards you more than 40 degrees causes the backlight to turn on.

ALARM
Month � Day

Hour : Minutes Alarm number

You can set up to five independent alarms with hour, minutes, month, and day. When the alarm is turned on, the alarm tone sounds when the time is reached. You can also turn on an Hourly Time Signal that causes the watch to beep twice every hour on the hour. � The alarm time (hour and minutes) and alarm number (1 though 5) indicates an alarm screen. :00 is shown in place of the alarm time on the Hourly Time Signal screen. � Alarm settings (and Hourly Time Signal settings) are available in the Alarm Mode, which you can enter using C.

Parallel to ground

More than 40 °

Alarm Types
The alarm type is determined by the settings you make, as described below. � Daily alarm Set the hour and minutes for the alarm time. This type of setting causes the alarm to sound everyday at the time you set. � Date alarm Set the month, day, hour and minutes for the alarm time. This type of setting causes the alarm to sound at the specific time, on the specific date you set. � 1-Month alarm Set the month, hour and minutes for the alarm time. This type of setting causes the alarm to sound everyday at the time you set, only during the month you set. � Monthly alarm Set the day, hour and minutes for the alarm time. This type of setting causes the alarm to sound every month at the time you set, on the day you set.

Warning! � Always make sure you are in a safe place whenever you are reading the display of the watch using the auto light switch. Be especially careful when running or engaged in any other activity that can result in accident or injury. Also take care that sudden illumination by the auto light switch does not surprise or distract others around you. � When you are wearing the watch, make sure that its auto light switch is turned off before riding on a bicycle or operating a motorcycle or any other motor vehicle. Sudden and unintended operation of the auto light switch can create a distraction, which can result in a traffic accident and serious personal injury.

To turn the auto light switch on and off In the Timekeeping Mode, hold down D for about two seconds to toggle the auto light
switch on ( displayed) or off ( not displayed). � The auto light switch on indicator ( ) is on the display in all modes while the auto light switch is turned on.

REFERENCE
This section contains more detailed and technical information about watch operation. It also contains important precautions and notes about the various features and functions of this watch.

To set an alarm time
1. In the Alarm Mode, press D to select the alarm whose time you want to set. Alarm 1 Time Signal Alarm 2 Alarm 5 Alarm 3 Alarm 4

Auto Return Features
If you leave a screen with flashing digits on the display for two or three minutes without performing any operation, the watch automatically saves anything you have input up to that point and exits the setting screen.

2. After you select an alarm, hold down A until the hour digits of the alarm time start to flash, which indicates the setting screen. � This operation automatically turns on the alarm. 3. Press C to move the flashing in the sequence shown below to select other settings. Hour Minutes Month Day

Data and Setting Scrolling
The D button is used to scroll through setting screen data on the display. In most cases, holding down this button during a scroll operation scrolls through the data at high speed.

Backlight Precautions

4. While a setting is flashing, press D to increase it. � To set an alarm that does not include a month (Daily alarm, Monthly alarm), set x for the month. Press D until the x mark appears (between 12 and 1) while month setting is flashing. � To set an alarm that does not include a day (Daily alarm, 1-Month alarm), set xx for the day. Press D until the xx mark appears (between 31 and 1) while the day setting is flashing. � When setting the alarm time using the 12-hour format, take care to set the time correctly as a.m. (no indicator) or p.m. (P indicator). 5. Press A to exit the setting screen.

To turn an alarm and the Hourly Time Signal on and off 1. In the Alarm Mode, press D to select an alarm or the Hourly time signal on indicator Hourly Time Signal. 2. When the alarm or the Hourly Time Signal you want is selected, press B to turn it on and off. � The lower graphic area shows the current on/off status of each of the five alarms. � The indicator appears on the display whenever the Hourly Time Signal is turned on. � The alarm on indicator and the Hourly Time Signal on indicator are shown on the display in all modes while 5 (on) these functions are turned on.
3 (on) Alarm 1 (on)

� The electro-luminescent panel that provides illumination loses power after very long use. � The illumination provided by the backlight may be hard to see when viewed under direct sunlight. � The watch may emit an audible sound whenever the display is illuminated. This is due to vibration of the EL panel used for illumination, and does not indicate malfunction. � The backlight automatically turns off whenever an alarm sounds. � The backlight remains lit for about two seconds from the point you press the button, even if it is already lit when you press the button. If you keep the button depressed for two seconds or more, the backlight automatically turns off. � Frequent use of the backlight shortens the battery life. Auto light switch precautions � In order to protect against running down the battery, the auto light switch automatically turns off approximately six hours after you turn it on. � Avoid wearing the watch on the inside of your wrist. Doing so causes the auto light switch to operate when it is not needed, which shortens battery life. If you want to wear the watch on the inside of your wrist, turn off the auto light switch feature.
More than 15 degrees too high

� The backlight may not light if the face of the watch is more than 15 degrees above or below parallel. Make sure that the back of your hand is parallel to the ground. � The backlight turns off in about two seconds, even if you keep the watch pointed towards your face.

� Static electricity or magnetic force can interfere with proper operation of the auto light switch. If the backlight does not light, try moving the watch back to the starting position (parallel with the ground) and then tilt it back toward you again. If this does not work, drop your arm all the way down so it hangs at your side, and then bring it back up again. � Under certain conditions, the backlight may not light until about one second after you turn the face of the watch towards you. This does not necessarily indicate malfunction of the backlight.

2 (off) 4 (off)
