2-5. Tilt Adjustment
1. Set the Factory mode to �Device Adjust/OTHER�. 2. Adjust the stand and put the main unit into the horizontal state. (The horizontal state of this unit is forward tilted by _4 d.)
A
B
Align the A with the center position of the B.
_4d
Lever
Stand
3. 4. 5. 6. 7. 8.
Then, enter the X TILT value to C0. Set the unit upward in vertically. Then, enter the X TILT value to C1. Set the unit downward in vertically. Then, enter the X TILT value to C2. Save the each values of C0, C1 and C2 described in step3, 5 and 7.
