TA-S9D SECTION 3 DISASSEMBLY
� This set can be disassembled in the order shown below.
3-1.
DISASSEMBLY FLOW
Note 1: The process described in
can be performed in any order. , the next process can not be performed.
Note 2: Without completing the process described in
SET
3-2. CASE (Page 6)
3-3. FRONT PANEL SECTION (Page 6)
3-4. BACK PANEL (DVD) SECTION (Page 7)
3-5. FRONT AMP BOARD (Page 7)
5
|
