SX-JS5/JS7

EXPLODED VIEW
NOTE: � -XX and -X mean standardized parts, so they may have some difference from the original one. � Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) � � Parts Color Cabinet's Color � Items marked �*� are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. � The mechanical parts with no reference number in the exploded views are not supplied.

Note: This set is the figure of Rch set.

not supplied

SP1 not supplied

not supplied

SP2

2

SP3

not supplied

not supplied SP4

not supplied

1

Ref. No. 1 1 2 SP1

Part No. A-4737-438-A A-4737-439-A 4-249-280-01 1-825-519-11

Description SYSTEM (L) ASSY (Lch) SYSTEM (R) ASSY (Rch) CAP, CERAMIC SPEAKER (14cm)

Remark

Ref. No. SP2 SP3 SP4

Part No.

Description

Remark

1-825-400-11 SPEAKER (CERAMIC) (2cm) 1-825-520-11 SPEAKER (14cm) 1-825-399-11 SPEAKER (6cm)

2
