Connecting to the Monitor
To install the speaker cord holders As shown in the figure, insert the holders into the holes on the ventilation openings. Evenly space the holders and insert them under the monitor cover.
Monitor cover
Securely insert the holders into the holes on the ventilation openings.
If you use an optional mounting bracket, the bracket position and the holder positions should not overlap.
Notes
� Be careful not to short-circuit the speaker terminals according to the wire sticking out of the insulation. � Connect the speaker cords with correct polarity. Correct �� connections of both speaker systems insures proper inphase operation. If the speaker system is out-of-phase, the bass tones seem to be missing and the position of the sound sources become obscure. � Do not connect the speakers to both an amplifier and a monitor at the same time. Otherwise, the excessive electric current may flow from the amplifier to the monitor via the speaker cord, which may damage the monitor.
To use an optional mounting bracket, insert the holders where the brackets are not installed. See the figure.
2 cm (13/16 inches)
12
Connecting to the Amplifier
Connect the cord to the speaker terminals of the AV amplifier.
Notes
� Do not connect the speaker system to the monitor and an amplifier. Doing so may cause a large amount of current to flow into the monitor from the amplifier via the speaker cord, resulting in damage to the monitor.
