SONY SSRS106
Manual de Servicio

EXPLODED VIEW AND PARTS LIST
NOTE: � -XX and -X mean standardized parts, so they may have some difference from the original one. � Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) � � Parts Color Cabinet's Color � Items marked �*� are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. � The mechanical parts with no reference number in the exploded views are not supplied.

4 2

not supplied

SP1

3 4

3

1

Ref. No. 1 2 3

Part No.

Description

Remark

Ref. No. 4 SP1

Part No.

Description

Remark

4-223-072-01 GRILLE 4-230-509-01 BOX 7-685-884-09 SCREW +BVTP 4X14 (S)

7-621-846-40 SCREW, WOOD +R 4.1X16 1-529-489-11 SPEAKER (10cm)

9-929-252-11
