SONY SSMSP2
Manual de Servicio

SS-CNP2/CRP2/MSP2
SERVICE MANUAL
Ver 1.0 2002. 02

US Model Canadian Model AEP Model UK Model E Model

SS-CNP2

SS-MSP2

� SS-CRP2 is the speaker section in HT-DDW740/DDW840.

� SS-CRP2 is composed of following models.
SS-CRP2 FRONT and SURROUND speakers CENTER speaker SS-MSP2 SS-CNP2

EXPLODED VIEW AND PARTS LIST

SPECIFICATIONS
Speaker system Speaker units Enclosure type Rated Impedance Full range, magnetically shielded 70 mm type 100 mm cone

1

Bass reflex 8 ohms

Power handling capacity (Maximum input power) 100 W Sensitivity level Frequcency range Dimensions (w/h/d) SS-MSP2 SS-CNP2 Mass SS-MSP2 SS-CNP2 85 dB (1 W, 1 m) 160 Hz � 20,000 Hz Approx. 81 141 121 mm (3 1/4 5 5/8 4 7/8 inches) Approx. 230 81 121 mm (9 1/8 3 1/4 4 7/8 inches) 0.8 kg (1 lb 13 oz) 1.0 kg (2 lb 4 oz)

2
Ref. No. 1 1 2 2 Part No. Description

A-4467-568-A OVERALL ASSY (SILVER) (SS-CNP2) A-4467-806-A OVERALL ASSY (BLACK) (SS-CNP2) A-4467-570-A OVERALL ASSY (SILVER) (SS-MSP2) A-4467-805-A OVERALL ASSY (BLACK) (SS-MSP2)

SPEAKER SYSYTEM
9-873-476-01
2002B1600-1 © 2002.02

Sony Corporation
Home Audio Company Published by Sony Engineering Corporation
