EXPLODED VIEW AND PARTS LIST
NOTE: � -XX and -X mean standardized parts, so they may have some difference from the original one. � Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) � � Parts Color Cabinet's Color � Items marked �*� are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. � The mechanical parts with no reference number in the exploded views are not supplied.

6 5 4 3

2
SP2

7

2
SP1

1

Ref. No. 1 2 3 4 5

Part No. 4-229-470-01 7-685-646-79 4-229-526-01 4-229-471-01 7-685-648-79

Description GRILLE (A), FRONT SCREW +BVTP 3X8 TYPE2 SLIT BOX GUIDE, SCREW SCREW +BVTP 3X12 TYPE2 SLIT

Remark

Ref. No. 6 7 SP1 SP2

Part No. 4-229-527-01 4-229-528-01 1-529-776-11 1-529-777-11

Description PLATE, REAR SCREW, BINDING SPEAKER (WOOFER) SPEAKER (TWEETER)

Remark
