SONY SSCHPX10W
Manual de Servicio

SS-CHPX10W
SERVICE MANUAL
Ver 1.1 2004.08

US Model Canadian Model AEP Model UK Model

� SS-CHPX10W is the speaker system in CMT-HPX10W.

SPECIFICATIONS
Speaker system Speaker units Super tweeter: Woofer: Tweeter: Nominal impedance Dimensions (w/h/d) Mass 3-way, bass-reflex type 2 cm dia., cone type 12 cm dia., cone type 4 cm dia., cone type 6 ohms Approx. 170 � 300 � 208 mm Approx. 2.7 kg net per speaker

EXPLODED VIEWS
1

Design and specifications are subject to change without notice.

Ref. No. 1

Part No.

Description

Remark

A-1061-010-A MAIN UNIT ASSY

SPEAKER SYSTEM
9-877-915-02
2004H16-1 © 2004.08

Sony Corporation
Personal Audio Company Published by Sony Engineering Corporation
