SONY SS-CHPR99
Manual de Servicio

SS-CHPR90/CHPR99
SERVICE MANUAL
Ver. 1.2 2007.02

US Model Canadian Model E Model
SS-CHPR90/CHPR99

Australian Model
SS-CHPR90

Photo: SS-CHPR90 � SS-CHPR90 is the speaker system in CMT-HPR90. � SS-CHPR99 is the speaker system in CMT-HPR95/HPR99XM.

Photo: SS-CHPR99

SPECIFICATIONS
SS-CHPR90 Speaker system: 2-way, bass-reflex type Speaker units Woofer: 13 cm dia., cone type Tweeter: 4 cm dia., cone type Nominal impedance: 4 ohms Dimensions (w/h/d): Approx. 174 � 280 � 258 mm Mass: Approx. 2.6 kg net per speaker SS-CHPR99 Speaker system: 3-way, bass-reflex type Speaker units Woofer: 15 cm dia., cone type Tweeter: 4 cm dia., cone type Super tweeter: 2 cm dia., ceramic type Nominal impedance: 4 ohms Dimensions (w/h/d): Approx. 182 � 320 � 244 mm Mass: Approx. 3.0 kg net per speaker Design and specifications are subject to change without notice.

PARTS LIST
Part No. Description Remark

A-1161-293-A OVERALL ASSY (SS-CHPR90) A-1175-325-A OVERALL ASSY (SS-CHPR99)

SPEAKER SYSTEM
9-887-116-03
2007B05-1 © 2007.02

Sony Corporation
Personal Audio Division Published by Sony Techno Create Corporation
