PIONEER S-MS800T-LR/XMC
Manual de Servicio

1

2

3

4

2. EXPLODED VIEWS AND PARTS LIST
A

NOTES:

Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation.

2.1 PACKING

B

There is no drawing

PACKING Parts List
Mark No. 1 2 3 4 5 6 7 8 9 Description Non-Skid Pad Speaker Cords (2.5 m) Poly Bag (for Foot) Poly Bag (for Screw & Eva) Poly Bag (for Cable Wire) Poly Bag (for Speaker) Poly Bag (for Grille Assy) Mirror Mat (for Speaker Top & Bottom) Carton Box (for S-MS800T-LR/XJM/E) (for S-MS800T-LR/XMC) Creasing Pad (Packing for Foot) Polystyrene Foam Polystyrene Foam Block Screw M4 x 25 (for Foot) Wooden Foot Operating Instructions (English/Spanish/Chinese) Part No. 4399 294 84541 8299 297 68030 4399 293 31855 4399 293 31900 4399 293 31902 4399 293 31955 4399 293 31956 4399 293 31958

C

4399 293 34301 4399 293 34295 4399 293 54130 4399 293 64176 4399 293 64178 4399 294 98234 8299 297 52706 4399 294 62459

D

10 11 12 13 14 15

E

F

2
1 2

S-MS800T-LR
3 4
