AUDIO SYSTEM ADJUSTMENTS
� Adjust both Lch and Rch. [Connection]
Audio generator 600 � Attenuator VCR Audiolevel meter or distortion meter 47 k�
CH1 RF SWP
OK CH2 NG
AUDIO LINE IN Feed signal both channelssimultaneously.
AUDIO LINE OUT
Fig. 7-2-4.
2-4-1. Hi-Fi Audio System Adjustment � Set switches and knobs to the following positions to make adjustment unless otherwise specified. INPUT SELECT switch ................... LINE AUDIO MONITOR .......................... STEREO [Adjustment Sequence] 1. AF Switching Position Adjustment 2. Frequency Responce Check 3. Overall Level Characteristic and Distortion Factor Check 4. Overall S/N Check 1. AF Switching Position Adjustment (MA-325 Board) Purpose: Adjust the interval between A CH and B CH of tape playback output. Improve the interchangeability with other tapes and sets. When it is out of order, noisy sound is increased and big noise is heard. Mode Signal Measurement point Measuring Instrument Specified Value PB Alignment tape SP mode color bar CH2: Pin 1 of CN341 CH1: Pin 3 of CN501 Oscilloscope Fig. 7-2-5 Signal
Fig. 7-2-5.
2. Frequency Responce Check Purpose: Confirm that the frequency characteristic is within the specification. Mode REC and PB (SP, EP, LP mode) 400 Hz, �7.5 dBs 20 Hz, �7.5 dBs 20 kHz, �7.5 dBs Audio output terminal Audio level meter 0 ± 2 dB
Measurement point Measurement equipment Specified value
Note: Tape path adjustment must have been completed. Confirmation Method: 1) Supply a signal of 400 Hz, �7.5 dBs to both L and R channels of Audio Line Input. 2) Connect the audio level meter to the Audio Line Output. 3) Adjust the attenuator so that the audio level meter will indicate �7.5 dBs. 4) Make recording. 5) Set an audio line input signal to 20 Hz and make recording. 6) Set an audio line input signal to 20 kHz and make recording. 7) Playback a recorded portion, and measure output levels at 400 Hz and 20 Hz and 20 kHz. 8) Confirm that the 20 Hz and 20 kHz playback output level within a range of the 400 Hz playback output level 0 ± 2 dB.
Adjusting Method: 1) Connect MA-325 board JS161 to the GND for about 1 second to activate the RF switching position adjustment mode. 2) Press the PAUSE button to activate the AF switching position adjustment mode. 3) Check appear �HFxx� on FL display. 4) Using the PROGRAM + and � buttons, minimize a chipped portion. At this time, confirm that a noisy sound is not heard. 5) Press the PAUSE button. 6) Press the EJECT button.
