Repair Item 2-B
~1.1 V
B
Figure 7
When the waveform at IRF with an osilloscope.
Is the waveform at IC102 pin 35 like that shown in fig. 7 ? Yes * Check IC103 pins 32, 34, 4, 5, 36, 37, 38, 57, 21 and circuit around them. * Check IC103 pins 8, 9 and 77. * IC104 or IC103 is defective.
No
* Check soldering of C159 and IC103 pins 35 and 21. * IC103 is defective.
8
|
|
 |
> |
|
|
