SETTINGS ______________________________________________
Stereo / two channel, mono
If the device receives two channel programmes, e.g. a film with the original sound on sound channel B (display: »Dual B «) and the dubbed version on sound channel A (display: »Dual A«), you can select the sound channel you desire. If the device receives stereo or Nicam programmes, it switches automatically to stereo sound (display: »Stereo«). You can switch the sound to »Mono« if the stereo reception quality is poor. 1 Select »Sound type« with »P+« or »P-« and adjust the setting with » « or » «.

Stereo width
Widens the audio output for stereo programmes and improves the sound with mono reception. 1 2 Select »Sound type« with »P+« or »P-«. Press » « or » « to select the setting.

Automatic volume
The television channels broadcast at different volumes. The automatic volume limiting (AVL) function means the volume is kept the same when you switch between channels. 1 Select »AVL« with »P+« or »P-« and then select »On« with » « or » «.

Equaliser
The equaliser offers you four preset sound settings (Music, Sport, Cinema and Dialogue) and one which you can create yourself (User).
Equalizer User
12 dB

1

Select »Equalizer« with »P+« or »P-« and confirm with »OK«. � The »Equalizer« menu appears. Select the audio setting »User« with »P+« or »P-« and confirm with »OK«. � The frequency band »120 Hz« is activated. Set the desired value with »P+« or »P-« and select the next frequency band with » « or » «. Press »F « (blue) to save the setting.

0 dB

2

-12 dB

<120Hz 500Hz 1.5kHz 5kHz 10kHz>

3 4

Select

Back Exit

q OK

and edit

Concluding the settings
1 Press »i« to finish the settings.

14
