CHAPTER 3. REPAIR INSTRUCTION

4

1. Place the camera so that lens is set against the light source surface of the Brightness Box via the C-12 Filter. 2. Set the Brightness Box to EV12. 3. Click the �Check� button. 4. Check the Brightness level if it is within 0 ± 5. * If not, calibrate the Brightness Box until it becomes within 0 ± 5. 5. Click the �NEXT� button.

C-12 Filter

Brightness Box CAMERA BODY Power Source

Personal Computer

5

1. When the message on the right appears, Set the Brightness Box to EV15 and attach the ND-8 Filter while setting the C-12 Filter between the lens. 2. Click the �Check� button. 3. Check the Brightness level if it is within 0 ± 5. * If not, calibrate the Brightness Box until it becomes within 0 ± 5. 4. Click the �NEXT� button.

6

When the message on the right appears go to 7.

7

1. Attach the ND-4 Filters between the Lens and the Color Viewer. 2. Place the camera so that the lens is set against the center part of the Color Viewer. 3. Click the �ADJUST� button.

Color Viewer

ND-4 Filter CAMERA BODY Power Source Stand

Personal Computer

3-24
