2. EXPLODED VIEWS AND PARTS LIST
NOTES : · Parts marked by � NSP � are generally unavailable because they are not in our Master Spare Parts List. · The> mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation.
A
2.1 PACKING
Refer to �2.2 BRACKET TOP and BRACKET BOTTOM SETS�.
B
Tape
C
Tape Tape
PACKING parts List
Mark No. NSP 1 2 3 NSP 4 5 6 NSP 7 NSP 8 9 10 11 NSP 12 13 14 Description 1..Accessory Set 2..Speaker Wire 2..Polyethylene Bag S1 2..Screws Set 3..Screw 3..Polyethylene Bag S0 Bracket Top Set Bracket Bottom Set Protector Protection Sheet S4 Packing Case 1..Inst. Manual Set 2..Polyethylene bag S2 2..Operating Instructions (English, French, German, Italian, Dutch, Spanish, Chinese) NSP 15 Label Serial SRW1112 Part No. SME3782 SDS6049 SHL1439 SME3783 BMZ50P100FTB SHL1438 SME3785 SME3786 SHA2585 SHC6063 SHG2784 SME3789 SHL1437 SRD1336
D
E
F
PDP-S60
5 6 7 8
3
|
