FOR PRECAUTION OF REASSEMBLY AND DISASSEMBLY
A
The grille is attached to the baffle using double-sided self-adhesive tape. To avoid damaging the grille, work with the speaker on top of a blanket or similar, face up. There are two slots in the lower part of the speaker. Insert a screwdriver(-) into each slot and push down detach the lower part. Turn the speaker over and insert a screwdriver(-) between the grille and the baffle. Taking care not to damage the baffle, push down on the screwdriver(-) to prize the baffle and grille apart. When reattaching the grille, use double-sided self-adhesive tape in the locations shown in the diagram and press the grille assy into place. The grille is fixed using boss and double-sided self-adhesive tape(The tape is in the locations indicated in the diagram below). Do not use a dryer to heat the self-adhesive tape when removing the grille. The woofer is attached to the baffle by external screws. To deC
GRILLE
Slot
B
Screwdriver(-)
Grille
tach it, unfasten those screws. When attaching it, face its terminal downward.
Down
The tweeter is attached to the baffle by external screws. To detach it, unfasten those screws.
Baffle
LOCATIONS TO FIX DOUBLE-SIDED SELF-ADHESIVE TAPE
(11) (11)
Tape (SEH1074 x2) D Tape (SEH1063)
E Tape (SEH1074 x2)
F
Tape (SEH1063)
2
1 2
PDP-S33-LR
3 4
|
