Inserting the Wireless LAN PC Card
If you are inserting the 5GHz Wireless LAN PC Card PCWA-C500 for the first time, see Quick Start Guide for details.
This section explains how to insert and remove the Wireless LAN PC Card from your computer. You do not need to turn off your computer when inserting the Wireless LAN PC Card.
To insert the Wireless LAN PC Card:
1
If your computer has a PC card slot protector, remove it from the computer.
Some computers offer a PC card slot protector to prevent damage to the PC card slot while it is not in use.
2
Insert the Wireless LAN PC Card in the PC card slot.
Note If you have an upper and a lower PC card slot, use the upper slot for the Wireless LAN PC Card. If you insert the card into the lower slot, the card's antenna may block the upper slot. See also �Notice for users who have a computer with an upper and a lower PC card slot� on page 14.
Push the Wireless LAN PC Card into the slot until it is firmly seated. Inserting the card will extend the eject button. If the card does not fit easily, do not force it. Remove the card and reinsert it.
