SONY PCVRZ
Manual de Servicio

� MEMORY

2 memory Note 1: In opening the clips, hold lightly the top of the memories with your fingers to prevent a drop. Note 2: In removing the memories, always start from the one having largest bank number. 1 Open clip.

1 Open clip.

MEMORY INSTALLATION
Note1 : With the clips left open, insert the memory so that boss of DIMM socket engage with slot of memory. Note2 : Make sure that clips are closed when the memory were inserted completely. Note3 : Insert the memory, starting from the one having smallest bank number. memory

clip

boss

DIMM socket

clip

Confidential
1-20 PCV-RZ Series (AM)
