CHAPTER 9 INSTALLATION

Step 8

Work Fit the shipping attachments [1] and [2] detached in step 5 back to the machine.

Checks and remarks

Shipping attachment [1]

Shipping attachment [2]

9 10

Tape the machine's top unit in place to prevent it from opening. Place A4/LGL copy paper on the copyboard glass, and close the copyboard cover; then, tape it in place. (Copyboard type only) Raise the ADF. Then, place two parts used as packaging so that they fit closely around both sides and the front of the ADF, as shown in the diagram, and secure them with tape. (ADF type only)

11

Gently lower the ADF and secure the main unit by taping in eight places, as shown in the diagram. (ADF type only) Pack the machine, using the original packing material and box. Or tape the machine�s top in place so that it will not open while in transit.

COPYRIGHT © 1999 CANON INC.

CANON PC800s/900s REV.0 AUG. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)

9-13
