MZ-RH10
Example of Calculation:
Result Item No. 0211 0212 0213 0214 0215 0216 Parameter Pr_nominal 2.48 mW Decimal 50 30 147 40 38 116 Hexadecimal 32h 1Eh 93h 28h 26h 74h
Kr �0.3 %/°C Pw_nominal 7.35 mW Kw �0.4 %/°C Prmin Pwmin 1.9 mW 5.8 mW
3-5-3. Other setting Procedure: 1. Enter the test mode (Display Check mode). 2. Press the [VOL+] key to enter the Manual mode. 3. Press the [VOL+] key once and press the > key five time to select the item number 1113 and display as follows.
Display of the remote commander
113 SS**$$##
adjustment value (hexadecimal)
Procedure: 1. Enter the test mode (Display Check mode). 2. Press the [VOL+] key to enter the Manual mode. 3. Press the > key once, press the [VOL+] key once, and press the > key once again to display as follows.
Display of the remote commander
210 DiscPr
4. Press the > key once to select the item number 0211. 5. Adjust with [VOL+]/[VOL--] keys so that the adjustment value of LCD becomes calculated value. 6. Press the X key on the set or � key on the remote commander to write the adjusted value. 7. Press the > key to next item. 8. Repeat adjustment from step 4 until item number 0216. 3-5-2. Destination setting Procedure: 1. Enter the test mode (Display Check mode). 2. Press the [VOL+] key to enter the Manual mode. 3. Press the > key five time to select the item number 0113 and display as follows.
Display of the remote commander
113 DistFL **
adjustment value (hexadecimal)
4. Adjust with [VOL+]/[VOL--] keys so that the adjustment value of �**� on the LCD becomes �1A�. 5. Press the X key on the set or � key on the remote commander to write the adjusted value. ($$ blinks and disc mark rotates on the LCD) 6. Adjust with [VOL+]/[VOL--] keys so that the adjustment value of �$$�on the LCD becomes �20�. 7. Press the X key on the set or � key on the remote commander to write the adjusted value. (## blinks and disc mark rotates on the LCD) 8. Adjust with [VOL+]/[VOL--] keys so that the adjustment value of �##�on the LCD becomes �94�. 9. Press the X key on the set or � key on the remote commander to write the adjusted value. 10. Press the [VOL+] key once to change the adjustment value of �**� on the LCD into �1B�. 11. Press the X key on the set or � key on the remote commander to write the adjusted value. ($$ blinks and disc mark rotates on the LCD) 12. Adjust with [VOL+]/[VOL--] keys so that the adjustment value of �$$�on the LCD becomes �F1�. 13. Press the X key on the set or � key on the remote commander to write the adjusted value. (## blinks and disc mark rotates on the LCD) 14. Adjust with [VOL+]/[VOL--] keys so that the adjustment value of �##�on the LCD becomes �1A�. 15. Press the X key on the set or � key on the remote commander to write the adjusted value. 16. Press the x key four times and back to the Display Check mode.
4. Press the [VOL+]/[VOL--] key and set the according value to each destination referring to the following table. 5. Press the X key on the set or � key on the remote commander to write the adjusted value. 6. Press the > key to select the item number 0114. 7. Repeat adjustment from step 3. 8. Press the x key four times and back to the Display Check mode.
Destination US and Canadian AEP, UK and East European E, Hong Kong, Korean, Australian and Tourist Setting value Item No. 0113 Item No. 0114 20 80 A0 24 80 80
Table 3-5-2. Destination Setting
19
|
|
|
> |
|
