GRUNDIG M 70-1690 DPL
Manual de Usuario

r

Assigning programme positions
This set is equipped with the automatic tuning system ATS euro plus which performs the programme assignment for you.

r

Basic operation
The dialogue symbols indicate for each operating step with which buttons the different functions can be carried out.
AV ATS

Video recorder and television set have been purchased brand new
The video recorder may only be connected to the mains after the automatic channel search has been completed.

TXT TV

The channels on the video recorder are already set, the TV set is new
Connect the TV set and the video recorder using the Euro-AV cable. After switching on the set, confirm the »English« dialogue language by pressing the button.

P OK P

O

If the »Select dialogue language« page does not appear, press the button until it does (approx. 5 seconds).

m
]/|
Yellow bar up/down
In two-page menus, selection of the second page.

Confirm your country with the

O button.
xc

When the automatic programme allocation is completed, hints to the Easy Dialog System are displayed.

Set values. Confirm selected function. Return to TV picture. Help.

r

The Easy Dialog System
Your television is provided with the »Easy Dialog System«. With this system, all hints on operating the TV set are no longer to be found in a printed instructions manual but in dialog boxes which can be displayed on the picture screen. If you should have any questions about handling this new system, please contact our consumer help desk Telephone Number: 01 80/5 30 21 22 1

O ¢ ¢
TXT

?

r

Dolby Surround Pro Logic*
To obtain the optimum sound impression with Dolby Surround Stereo broadcasts, you will require additional loudspeaker boxes (see Fig. A on last page). For this, we recommend you the following principal solutions: As front speaker boxes, you can use the already existing boxes of your hifi equipment. For this, connect your hifi equipment to the AUDIO OUT sockets (see Fig. B).

r

The Dialogcenter
The Dialogcenter is the control centre of your TV set. It is called up by pressing the . and button. Via the displayed menu, you can make settings, call up information and select precise help for operating your TV set (for example an explanation of the remote control handset, an index, tips and tricks, etc.).

O

2

Additional front boxes are to be connected to the sockets L and R. The centre box is to be connected to the �Center� socket (see Fig. C). As front boxes, we recommend the GRUNDIG PD 1 boxes or commercially available boxes having a nominal impedance of at least 8 Ohms.

Simply try it out. You can do no harm!

3

The Surround boxes are to be connected to the �Surrround� socket (see Fig. D). If several boxes are connected to the surround channel, please make sure that the nominal impedance does not fall below 8 Ohms. * Under licence from Dolby Laboratories Licencing Corporation. DOLBY and the double-D symbol are trademarks of Dolby Laboratories Licencing Corporation.

Easy Dialog System
7
