(2) MAIN BRACKET REMOVAL
* Pay particular attention to the wires of each PCB when puling out the main bracket.

� KP-EF41

� KP-EF53
1 Two screws (Hexagon head)

3 Set the main bracket. 2 Pull the main bracket.

1 Two screws (Hexagon head)

3 Set the main bracket. 2 Pull the main bracket.

� KP-EF48

� KP-EF61

1 Two screws (Hexagon head)

1 Two screws (Hexagon head)

3 Set the main bracket.

2 Pull the main bracket.

3 Set the main bracket.

2 Pull the main bracket.
