KENWOOD KNADV4100
Manual de Servicio

DVD NAVIGATION SYSTEM

KNA-DV4100
SERVICE MANUAL
© 2004-5 CREATED IN JAPAN B53-0176-00 (C) 0

Dressing panel assy (A21-4437-03)

Panel assy (A64-3493-03)

DC cord assy (E30-4964-05)

Connecting cord assy (E30-6199-05)

Electric circuit module(GPS ANT) (W02-3261-05)

Mounting hardware (J21-9867-04)

Bracket (J19-5246-04)

Screw set (N99-1713-05)

DVD (W01-1636-05)

KNA-DV4100 is the same as KNA-DV3100 except the following information. Please refer to the service manual (B53-0050-00) of KNA-DV3100. The DVD mechanism of KNA-DV4100 is X92-4750-00. Please, refer to sarvice manual X92-4750-00 (B530052-00) for DVD mechanism infomation. CAUTION (Repair of NAVI board ) You can not repair IC521 (GPS Receiver) and IC701 (CORE1). If you can repair those parts please change to NAVI board assy(W02-3395-15).

�New Parts
201 204 PA1 232 VME1 IC7

PARTS LIST
Parts No. KNA-DV4100 A01-2821-02 METALLIC CABINET DRESSING PANEL ASSY PANEL ASSY INSTALLATION MANUAL INSTRUCTION MANUAL ITEM CARTON CASE Description

Ref. No. New

� � � � � �

A21-4437-03 A64-3493-03 B54-4444-00 B64-2891-00 H54-3231-03

W01-1636-05 DVD X92-4750-00 DVD MECHANISM ASSY DVD UNIT (X37-1020-03) DF2328VTE256Q7 MICROPROCESSOR IC
