KENWOOD KDC-C715
Manual de Servicio

CD AUTO CHANGER

KDC-C715/Y

KDC-C715/Y
SERVICE MANUAL
© 1999-12 PRINTED IN JAPAN B51-7553-00 (N) 3444 When transporting this model, always attach CAUTION CARD and STEPPED SCREW (for transportation). CAUTION CARD : B58-1275-04 STEPPED SCREW : N09-4186-25
Dressing Panel (A21-3536-12) Dressing Panel (A21-3539-12) Panel (A64-1992-01)

Service jig For initial position setting

Parts No. W05-0635-00

COMPACT DISC AUTO CHANGER
NEW ANTI VIBRATION MECHANISM
COMPACT

KDC-C715

DISC NAME PRESET

DIGITAL AUDIO

TEXT

10 DISC

Holder Assy (Magazine) (J19-4676-52)

Bracket (L) (J19-4710-13) Bracket (R) (J19-4711-13)

Blind Plate (F19-1303-04)

Screw Set K/E Type: (N99-1645-15) M Type: (N99-1628-15) Mounting Hardware Assy (J21-7775-04) M Type Only

Adhessive Tape (J69-0506-04)

Cord With Plug (E30-4138-05)

The MECHANISM OPERATION DESCRIPTION is the same as model KDC-C710. Please refer to the service manual of model KDC-C710 (B51-7104-00).
