KDC-7027/7027Y
TEST MODE
� Security information 1. Forced Power ON mode (All models)
Even when the security (Cord) is approved, resetting the unit while holding the Q and Preset 4 keys makes it possible to turn the power ON for 30 minutes. After 30 minutes have elapsed, it is not possible to return to the previous condition unless the unit is reset again. (Security code is doing not clear at this mode. Put the power on fill-in.) When panel security was set up for the unit when it is can not power on. In this case, you can use new ROM for the TDF panel that the unit can be power on for test mode. Note : Don�t enter the panel security set up for new ROM panel. User can not power on the unit.

3. How to inscription the panel security code
1. Enter the test mode. 2. Pressing the AM key on all lighting, check the �P-ROM WAIT� display. 3. The NEXT key is long press 2 seconds, writing the code. 4. Display is �P-ROM OK�. 5. Exit from the test mode. Note : E2PROM connection is NG when display is �P-ROM NG�, so detach the panel and rewrite after the display is �PROM WAIT�. This code can not clear.

2. Method of registration of the security code after EEPROM (F/E) replacement (Code security model)
1. Enter the test mode. (See How to enter the test mode) 2. Press the MENU key to enter the Menu mode. 3. When the message �Security� is displayed, press and hold the Track Up/Down key for 1 second to enter the security registration mode. 4. Enter the code using the FM/AM/Track Up/Track Down keys. FM key : Number up AM key : Number down Track Up key : Cursor right shift Track Down key : Cursor left shift 5. Hold down the Track Up key for at least 3 seconds and the message, �RE-ENTER� appears, so once again enter the code according to Step 4 above. 6. Press and hold the Track Up key for 3 seconds until �APPROVED� is displayed. 7. Exit from the test mode. (See 2. How to exit from the test mode) Note 1 : All Clear is not applicable to the security code of this model. Note 2 : When the F/E changed, need re-inscription because the panel security is clear.
