Inicio >> KENWOOD >> KDC225 Manual de Servicio

 0 artículo(s) en Su carrito

KENWOOD KDC225
Manual de Servicio


¡Twitee acerca de este producto y obtenga $1.00 de crédito en la tienda para uso!
  • Contiene diagramas del circuito
  • Descargable
  • Formato PDF
  • Manual completo
  • Idiomas: English
Precio: $4.99

Descripción del KENWOOD KDC225 Manual de Servicio

Manual de servicio completo en formato digital (archivo PDF). Los manuales de servicio por lo general contienen diagramas de circuitos, tarjetas de circuitos impresos, consejos para reparación, diagramas de cableado, diagramas de bloque y lista de refacciones. El Manual de Servicio (a veces llamado Manual de Reparación) es usado principalmente por los técnicos.

Si tan solo quiere saber cómo utilizar su televisión, reproductor de vídeo, reproductor de mp3, etc. Quizá lo que necesita es el Manual del Propietario. Después de colocar la orden le enviaremos las instrucciones de descarga a su dirección de e-mail.

The manual is available in languages: English

Not yet ready
You must purchase it first

Opiniones de los clientes
No hay comentarios de productos.

TEXT_PDF_SNIPPET
KDC-225/225MR/2025
TEST MODE
1. How to enter test mode
While holding the FM key and PRESET 6 keys, reset the unit. All display segments light up when the test mode is entered.

6. AUDIO function � Audio-related specifications
� A short press of the Q key initiates the audio adjustment mode. � Pressing the OPEN/CLOSE key on the remote controller initiates the audio adjustment mode. � Continuous holding of a remote control key is inhibited. � Bass, Middle and Treble are adjusted in 3 steps of -8 / 0 / +8 with the Track Up/down keys (default is 0). � Balance is adjusted in 3 steps of Left L15 / 0 / R15 Max with the Track Up/down keys (default is 0). � Loudness : OFF

2. How to exit from test mode
Reset the unit. Turning ACC off, power off, momentary power down or panel detaching does not terminate the test mode.

3. Initial status in the test mode
� Sources : ALL OFF (STAND BY) � Display : All segments were lit. � Volume : -10dB (displayed as �30�) � Loudness : OFF � CRSC : OFF regardless of the presence of switching function. � Aux : ON

7. MENU function � Menu-related specifications
� A short press of the PLAY/PAUSE key initiates the Menu mode. � Pressing the DNPP key on the remote initiates the Menu mode. � Continuous holding of a remote control key is inhibited.

4. TUNER function � Forced switching of K3I
Each press of the Preset 6 key in Tuner mode should switch K3I from AUTO�Forced Wide�Forced Middle�Forced Narrow�AUTO. The initial status is AUTO and the display shows these modes as follows. � AUTO : A � Forced Wide : M � Forced Middle : M � Forced Narrow : N

8. OTHER � Special display when the display is all on
Pressing the Preset keys while the power is ALL OFF displays the following information.
[PRESET 1] [PRESET 2] [PRESET 3] Version display (Month/Day/Hour/Minute) ALL segment light up for FL display Short press : Display CD operation time. Long press/hold : Clear CD operation time [PRESET 5] Short press : Display CD ejection count. Long press/hold : Clear CD ejection count. [FM] ROM correction version. If not mounting ROM correction chip set display shows ROM No___

� RDS check
PCON is power off when RDS data (�RDS test�) received for TUNER mode.

5. CD function � Test mode specifications of the CD receiver
� Each press of the Track Up key jumps to the following track numbers : No. 9�No. 15�No. 10�No. 11�No. 12�No. 13�No. 22 �No. 14�No. 9 (The cycle restarts from here.) � Each press of the Track Down key jumps to the previous track number to the track being played. � When the number of total tracks of disc is nine or less, unit playback from a track 1. � When the media to CD-DA, unit playback from track No. 28 by key operation of preset 1 key.

7
