KENWOOD KDC115S
Manual de Servicio

KDC-1016/115S
SPECIFICATIONS
Model FM Frequency Range (Frequency step) Channel Space Selection Usable Sensitivity (S/N 30dB) Quieting Sensitivity (S/N 50dB) Frequency Response (±3.0dB) S/N Selectivity Stereo Separation Frequency Range (Frequency step) Channel Space Selection Usable Sensitivity (S/N 20dB) Laser Diode Digital Filter(D/A) D/A Converter Spindle Speed Wow & Flutter Frequency Response THD S/N Ratio Dynamic Range Channel Separation KDC-115S 87.9MHz-107.9MHz (200kHz) 50kHz/200kHz 9.3dBf (0.8µV/75�) 15.2dBf (1.6µV/75�) 30Hz-15kHz 70dB(MONO) �80dB(±400kHz) 40dB(1kHz) 530kHz-1700kHz (10kHz) 9kHz/10kHz 28dBµ(25µV) GaAlAs (λ=780nm) 8 times Over Sampling 1 Bit 500-200rpm(CLV) Below Measurable Limit 10Hz-20kHz(±1dB) 0.01%(1kHz) 96dB(1kHz) 93dB 85dB 1800mV/10k�(CD) �600� 45Wx4 22Wx4 100Hz±10dB 10kHz±10dB 14.4V 10A 182mm 53mm 160mm 3.1lbs KDC-1016 87.5MHz-108.0MHz (50kHz) 50kHz/200kHz 9.3dBf (0.8µV/75�) 15.2dBf (1.6µV/75�) 30Hz-15kHz 70dB(MONO) �80dB(±400kHz) 40dB(1kHz) 531kHz-1611kHz (9kHz) 9kHz/10kHz 28dBµ(25µV) GaAlAs (λ=780nm) 8 times Over Sampling 1 Bit 500-200rpm(CLV) Below Measurable Limit 10Hz-20kHz(±1dB) 0.01%(1kHz) 96dB(1kHz) 93dB 85dB 1800mV/10k�(CD) �600� 45Wx4 22Wx4 100Hz±10dB 10kHz±10dB 14.4V 10A 182mm 53mm 160mm 3.1lbs

AM

CD

Preout Level/Load Preout Impedance AMPLIFIER

TONE GENERAL

Maximum Power Full Bandwidth Power (at less than 1% THD) Bass Treble Operating Voltage (11V�`16V allowable) Current Consumption Installation Size (W) (H) (D) Weight

7-3/16inch 2-1/16inch 6-5/16inch (1.4kg)

7-3/16inch 2-1/16inch 6-5/16inch (1.4kg)

KENWOOD follows a policy of continuous advancements in development. For this reason specifications may be changed without notice.
