I/O
I I I I I I � O O O O O O � O O O I O O O O O I O I/O I/O I/O I/O I/O I/O I I I/O I/O I/O I/O O O RDS signal level input. (Not used) Multi jog rotary encoder signal input. Function rotary encoder signal input. Key input (A/D). Tune-IF count serial data input. GND. BBE boost level control signal output. Tape monitor control signal output. ECO LED ON/OFF output. VIDEO-SW control signal output. Relay switch ON/OFF output. Sub-woofer ON/OFF output. Connected to GND through a resistor. VIDEO1 LED ON/OFF output. VIDEO2 LED ON/OFF output. VIDEO3 LED ON/OFF output. Headphone mute detected input. CD LED ON/OFF output. AUX LED ON/OFF output.
Description
Volume rotary encoder signal input (Main volume left & right).
TAPE MONITOR LED ON/OFF output. TUNER LED ON/OFF output. PHONO LED ON/OFF output. Tuner stereo detected input. FL segment P1 ~ P3 output. LW data input to diode (not used) / FL segment P4 output. RDS data input to diode (not used) / FL segment P5 output. BBE data input to diode (not used) / FL segment P6 output. AM stereo, wide band data input to diode (not used) / FL segment P7 output. AM10K data input to diode / FL segment P8 output. KARAOKE data input to diode (not used) / FL segment P9 output. Power supply input. Power supply input for FL display. DSP data input to diode / FL segment P10 output. DIGTITAL-IN1 data input to diode / FL segment P11 output. 96KHZ data input to diode / FL segment P12 output. DIGITAL-IN2 data input to diode / FL segment P13 output. FL segment P14 ~ P17 output. FL grid G12 ~ G1 output.
