SONY HTCNX1
Manual de Servicio

CHASSIS (MOLD B) SECTION, STOCKER SECTION AND SLIDER (SELECTION)
Note: In mounting the parts, refer to page 11 and 12.
6 two screws (PTPWH M2.6) 5 stocker section

7 slider (selection) 8 washer

9 compression spring

pulley (LD)

1 three screws (BVTP M2.6)

4 two step screws

2 chassis (mold B) section Note: Rotating the pulley (LD), shift the slider (selection) to the left.

4 two step screws

3 gear (eject)

GEARS INSTALLATION
3 gear (gear B)

portion A

Adjust the gear (gear B) with the portion A as shown.

1 Slide the slider (U/D) fully in the arrow direction.

4 gear (gear A) 2 gear (U/D slider) slider (U/D) gear

gear (gear B)

linearly

Adjust the gear so that it meshes with the bottom tooth of slider (U/D)gear, as shown.

Adjust so as to be aligned with gear (B) linearly,as shown.
