KENWOOD GX608EF2
Manual de Servicio

GX-608EF2
RDS DESCRIPTION
Differences in the RDS function between the overseas market model and the SUBARU GENUINE model
RDS function AF search Market model Can be switched on and off. · Default: On SUBARU GENUINE model Fixed to on. · AF search cannot be disabled. · With the auto memory function, only RDS stations can be set in the memory for the FM band. Fixed to off. · Even when TI is turned on, if the station currently tuned in is not a TP station, it is never interrupted for traffic announcements. Auto antenna control is conducted. · Even when set to another source, if an FM station is tuned in in the background, the auto antenna output is turned on. When pressed normally: 1 step up/down When pressed and held in: Auto seek · No continuous manual up/down · No AUTO 2 SUBARU GENUINE model preset scan is conducted. · Tuning switches up to the next preset channel every 10 seconds. Once all the channels have been scanned once, preset scan does not stop but continues in the same band. TI, news and alarm interruptions If the source is switched during an interruption, the interruption is suspended and to which the unit has been the source switched is played. This suspension of the interruption is canceled under the following conditions: (1) When the interruption broadcast (TA ON or PTY = 1 or PTY = 31) ends. (2) When RDS data could not be received for 15 seconds. (3) When the power is turned off/on, ACC is turned off/on or there is an instantaneous power failure. (4) If the TI interruption function is turned off/on with the TI key while the TI interruption is suspended. (5) If the news interruption function is turned off/on with the NEWS key while the news interruption is suspended. (6) When TEL MUTE is turned on/off. (7) When the band or the frequency is switched (included preset call) while interruption is suspended on the FM band. However, if the station is switched with AF search, suspension continues. News interruption disable time The news interruption disable time cannot be set.

AUTO TP search

Can be switched on and off. · Default: On

Auto antenna

No auto antenna control for the E type.

UP/DOWN key versions

The UP/DOWN key operation is set with the menu.

PRESET SCAN

No preset scan function

Source switching during interruption

TI and alarm interruption If the source is switched during an interruption, the source to which the unit returns after the interruption changes, but the interruption continues. If the source is set to all off, all off is set after the interruption is finished.

News interruption If the source is switched during an interruption, the interruption is suspended, and after the disable time the unit interrupts if PTY = 1. If the disable time is set to 0 minutes, the unit re-interrupts after 10 seconds. TEL MUTE during interruption (for TI, news and alarm interruptions) When TEL MUTE is generated, the interruption is suspended and the unit returns to the source prior to the interruption once TEL MUTE is canceled, but if the broadcast is still on, a new interruption is generated.

TEL MUTE during interruption (for TI, news and alarm interruptions) The operation during TEL MUTE is the same as for the market model.

9
