2-2. MEMORY CARDS REMOVAL AND MOUNTING
n Make sure that the fan is on your left side during this work. In the following explanation, �right� and �left� mean the directions from this position.
Removal
1. Expanding the fixing springs on the both sides by fingers, remove a memory card by pulling it down.
Memory Card
Fixing Spring
Mounting
1. Insert one memory card at an angle into an inner connector of the two vacant connectors.
Front of main unit Memory Card
Notched part
Center groove of the connector Holding a memory card with the notched edge on the left side (the front direction of the main unit), insert the memory card at an angle to the center groove of the connector.
