CANON EOSD30
Manual de Usuario

Inserting and Removing the Battery Pack
Inserting the Battery Pack
Load a fully charged BP-511 battery pack into the camera.

1 2

Open the battery chamber cover.

q Slide the lever in the direction shown by the arrow in the diagram, and open the cover as shown.

1

Load the battery into the camera.

q Make sure the battery pack is facing the right way, and insert it into the battery chamber. q Insert the battery pack until it locks into place.

3

q Press the cover closed until it clicks shut.

Close the cover.

Battery Charge Remaining Icons
The level of charge remaining is shown in three stages when the Main Switch is set to � ON �. (¡33)

Before You Begin

: Charge is sufficient. : Charge is low. : Battery pack must be charged.

If the level of charge remaining runs out when you are using the menu screen or playing back an image, a no battery warning appears on the LCD monitor. When this occurs, remove the battery and charge it.

27
