Coding
If you enter an incorrect code number: >SAFE < remains in the display. Radio does not play. Try again. Note the "waiting period" between the attempts.
Installation and removal
You will find illustrations of the text at the beginning of this booklet.
Waiting period
To ensure that your unit is not put into "operation" by someone testing it out , there is a waiting period between each attempt. During this period, no entries can be made: >SAFE < is shown in the display. The waiting period is over when the number of the attempt appears in the display, i.e. > 2 � � � � <. The table below shows the waiting period between the individual attempts. After the 5th attempt, we recommend that Failed attempts Waiting period your have your (in the display) (approx.) dealer put the unit into opera21 sec. tion. 1 1.5 min. There is always 2 5.5 min. a 24 hour wait3 22 min. ing period after 4 1.5 hrs. the 6th failed 5 6.0 hrs. attempt! 6 24 hrs. 7 24 hrs.
o�
Installation material and accessories
Your dealer can tell you wich installation materials you need and wich accessories are available.
Deactivating the coding
Before removing the radio: 1. Radio is playing Press the FM button until >SAFE < appears in the display. After approx. 3 seconds: > � � � � < appears in the display.
Supply voltages
Car radio without RS*: first »Inserting the mounting frame«, page 9! Contact blades A8 to A2: Illustration p
�
2. Enter code number (see identity card): Press buttons 1 � 4 until the code number appears in the display (see example in the "Activation" section).
��
� operating power A8 Connect to terminal 31 (ground wire) of the vehicle.
A7
+12 V operating power
With vehicles from the VW/Audi company as of the 1991 model: do not, under any circumstances, connect the contact blade A 7 to the S contact of the vehicle (power supply plug, PIN 4, brown/red cable). Connect terminal 15 or terminal 30 of the vehicle: � Terminal 15: if you want to be able to switch the radio on and off with the ignition switch, connect contact blade A4 to terminal 30! *Release System (RS), on page 3
3. Confirm code number: Press the FM button until >CODE< appears in the display. After approx. 3 seconds, the radio begins to play. If you enter an incorrect code number: >SAFE < remains in the display. Radio does not play. Try again. Note the "waiting period" between
�
the attempts.
8
|
|
|
> |
|
