Tray cannot be pulled out when it is not positioned properly . (When the two hooks hide under the rotary tray and cannot pull out the tray.) In that case, adjust the tray with the following procedures. Rotary Tray
1 1
B
Remove Tighten
Note : You don't need to match the disc numbers (1 to 5) when you return the tray. This is detected automatically.
2
Set the tray to the position where you can see the center hole.
C
7 8
Remove the mechanism section (screws � 4) Disconnect the three flexible cables and the connector
