3-2-9. Tape Streamer Access Error
. 098235 : Tape streamer does not access cassette It is detected that a cassette is attempted to be inserted from this unit to the tape streamer but failed. The tape streamer is suspected to be defective. Error display 098235 Check . Check whether the power switch of the tape streamer is turned ON normally or not. . Check the shutter plate of the tape streamer. . Check whether the correct cassette is used or not. The DTF cassette (GW-240S, GW-730L) only is available for the tape streamer. . Check the cassette compartment of the tape streamer. OK Close and lock the front door. NG Check/adjust the tape streamer. Starting up
. 098236 : Tape is not ejected from tape streamer It is detected that a cassette cannot be ejected even though an attempt is made to remove the cassette from the tape streamer. The tape streamer or eject sensor of this unit is suspected to be defective.
Error display 098236 Check . Check whether the correct cassette is used or not. The DTF cassette (GW-240S, GW-730L) only is available for tape streamer. . Check the shutter plate of the tape streamer. . Check the cassette compartment of the tape streamer. OK Open, close and lock the front door. NG Turn the power switch OFF and back ON. Is �>[E] S-HN FAIL� displayed in the display panel? NO YES
Repair faulty connections of the 40-core harness between HN-241, HN-254 and CPU-233 boards. Close and lock the front door. NG Turn the power switch OFF. Replace the part(s) in the following order: 1 SE-364 board NG 2 SE-365 board NG 3 SE-403 board NG 4 SE-404 board OK
Replace the part(s) in the following order: 1 HN-236 board NG 2 HN-254 board NG 3 CPU-233 board
Close and lock the front door. Turn the power switch ON. Starting up
