DCR-TRV33/TRV33E
2-4. MA-421 BOARD
8 Remove the MA-421 board in the way of twisting it in the direction of the arrow 9 HP sheet 6 Microphone 5 Microphone retainer 3 Microphone (4P)
4 Tapping screw (M1.7 � 5) 2 MA cover, MA cover cushion
q; MA-421 board 7 Two tapping screws (M1.7 � 5)
Caution
When installing the MA-421 board, attach the HP sheet so that the metal terminals of the headphones jack are hidden (insulated) by the HP sheet. Metal terminal part
1 Three tapping screws (M1.7 � 5)
Headphone jack
HP sheet
2-6
|
|
 |
> |
|
|
