2-7. VC-245 BOARD
REMOVING THE VC-245 BOARD
VC-245 board
Two claws
2 Remove the VC-245 board in the direction of the arrow.
8 VC-245 board
4 Flexible board (from capstan motor) (27P) 5 FP-102 flexible board (27P) 6 Flexible board (from video head) (10P) 7 Flexible board (from drum motor) (10P) 3 Control switch block (FK-30350) (39P)
-245 VCard Bo
5 24 C- d V ar Bo
1 Three screws (M1.7 � 2.5), lock ace, p2
2-8. MECHANISM DECK
3 Open the cabinet (G) assembly, MD frame assembly in the direction of the arrow A.
REMOVING THE CASSETTE COMPARTMENT COVER
1 Two screws (M1.7 � 2.5), lock ace, p2 3 Mechanism deck 2 Two screws (M1.4 � 1.5)
B A 1 Two screws (M1.4 � 1.5) 2 Cassette compartment cover
4 Two dowels
5 Remove the mechanism deck, Cassette compartment cover in the direction of the arrow B. (Be careful not to damage the mechanism deck´s flexible.)
2-6
|
|
 |
> |
|
|
