Recording a picture Adjusting the brightness of the LCD screen
(1) In the standby/recording mode, press FN and select PAGE2 (p. 15). (2) Press LCD BRT. The screen to adjust the brightness of the LCD screen appears. (3) Adjust the brightness of the LCD screen using �/+. � : to dim +: to brighten (4) Press OK to return to PAGE1/PAGE2.
1
FN
180°
2,3
LCD BRT
�
LCD BRT OK
+
90°
the bar indicator
OPEN
To return to FN
Press EXIT. Note When using the LCD screen except in the mirror mode, the viewfinder automatically turns off. When you use the LCD screen outdoors in direct sunlight The LCD screen may be difficult to see. If this happens, we recommend that you use the viewfinder. When you adjust angles of the LCD panel Make sure if the LCD panel is opened up to 90 degrees. Picture in the mirror mode The picture on the LCD is a mirror-image. However, the picture will be normal when recorded. During recording in the mirror mode ZERO SET MEMORY on the Remote Commander does not work. Indicators in the mirror mode The STBY indicator appears as Xz and REC as z. Some of the other indicators appear mirror-reversed and others are not displayed. When you press FN The does not appear on the LCD screen or in the viewfinder. LCD screen backlight You can change the brightness of the backlight. Select LCD B.L. in the menu settings (p. 76).
20
Even if you adjust the LCD screen backlight or brightness of the LCD screen The recorded picture will not be affected.
