3) Check the number of jams that occurred with reference to how LED2 flashes: � The maximum number of jams may be as high as '65,000'. F05-104-03 4) At the end of the check, press the push switch (SW2) on the ADF controller PCB once again.
1.4.2 Tray Pickup Counter and Manual Feed Pickup Counter
1) Remove the screw, and detach the ADF controller cover. 2) Set the DIP switch (SW1) on the ADF controller PCB as indicated to suit the need.
Item
Tray pickup counter
Setting
Manual feed pickup counter
T05-104-02 3) Press the push switch (SW2) on the ADF controller PCB. � LED2 will start to flash to indicate the total number of pickups made.
J1 FU2 J14
