CHAPTER 5 TROUBLESHOOTING

4) Open the DADF slowly, and measure the copy paper stop position 4; then, close the DADF.
Copyboard glass

�

Push Switch and Shift
Push switch SW1 SW2 Direction of shift Rear Front

Table 5-103
4

Copy paper

Note: Holding down the push switch will not cause more than a single shift.

Standard:

4

= 11.0 ±1 mm

DADF

Figure 5-115 5) To adjust the original leading edge stop position, use the push switches (SW1 and SW2) on the DADF controller PCB. Each press on the push switch will shift the original stop position by 0.34 mm. When the correct position is attained, press the push switch (SW3) once. The copy paper will be discharged and the new setting will be stored.
Copy paper
Leading edge Trailing edge

Copyboard glass

Figure 5-117 <EX.> Suppose that the copy paper stop position L4 is 10 mm from the edge of the copyboard glass when the push switch (SW3) on the DADF control PCB has been pushed once to stop the copy paper on the copyboard glass and the DADF has been opened. Close the DADF slowly without removing the copy paper, To shift the copy paper stop position toward the rear by 1.6 mm, 1.6 mm/0.34 (adjustment pitch) = 4.70 the push switch (SW1) should be pressed five times. Press the push switch (SW1) five times, and press the push switch (SW3) on the DADF controller PCB once so that the copy paper will be discharged and the new setting will be stored in memory.

1

2

1

4

12

1

10

1

9

J15
7

J5 CB1 J1 J2 J3 J14 J8
13 14

1 1 2 1

2

1 8

J13 J6

J10
1

3 1 2

J7

DSW1 SW1 SW3 SW2 TP1
B12 B1 2 A1 1

J11
1 3

J9

A12

J12

Figure 5-116
