Thank you for buying this Pioneer product. This speaker stand should only be used with the S-7EX Pioneer speaker system. Please read through these operating instructions for proper assembly and use. After you have finished reading the instructions, put them away in a safe place for future reference.
Assembling the speaker stands
Assemble the speaker stands as illustrated below. Please note that a flathead screwdriver will be necessary for assembly. The following illustration shows the fully assembled speaker stand:
Screw slots for securing speaker
Before you start
Before setting up your speaker system, we recommend reading the operating instructions for your system thoroughly.
Speaker support
Stand stems
� Only use the screws supplied when fixing the speaker to the speaker stand. � Do not place the stand on an unstable and/or sloping surface. The stand and speaker may fall and cause injury. � Do not use with any speaker system other than the one for which the unit was designed. The stand may collapse and be damaged and/or the speaker may fall and cause injury. � When moving the speaker and stand, first remove the speaker from the stand, and then move the stand, holding it by the two stems.
Stand base
� Align the screw slots on the stand base and screw holes on the speaker support with the screw holes in the two stems, then insert the screws and tighten. The screw slots allow you to fine-tune the positioning of the speaker.
Screws (Bind head, M6xL55)
Installing the speaker stands
Place the stand on a stable, level surface; placing the stand on an unstable surface can be dangerous.
Speaker support Stand stems Stand base 55 mm Black (SBA6051) Please note that sunken screw holes are provided in the speaker support.
Adjust the position as necessary to obtain optimal sound from your system.
Screws (Bind head, M6xL40) Nut Spike (SBA6053) 40 mm Spike base (SLA1057) Black (SBA6054)
� Pioneer assumes no liability whatsoever for damages resulting from assembly, improper mounting, insufficient reinforcement, misuse of the product, acts of nature, etc.
� Make sure you assemble the stand on a flat surface that is relatively soft (such as a carpet). � Make sure the screws are inserted in the screw holes as shown above (with the screw head hidden) when securing the speaker. Improper setup could result in damage or injury if the speaker falls from the stand.
2 En
|
|
|
> |
|
