SENSOR ALIGNMENT Perform this adjustment after the �holder (disc A) adjustment�. If the disc table swings to the left and right just before the disc is chucked, perform the following adjustment.
Cam LEVER (stopper) assembly
Cam
(1)Rotate the cam and adjust to the position shown in the figure.
Bracket (sensor)
Table assembly
(2)Check that the lever (stopper) assembly secures the disc table as shown in the figure.
Disc table
Swing Lever (stopper) assembly
(4)Moving the disc table right and left with a hand after the screw is fixed, the table will move by the play of a disc table. If the LEDs light up alternately, the adjustment will be performed correctly.
Tapering screwdriver
Luminus board
PLAY button Bracket (sensor)
PAUSE button
Fixed screw
(3)Loosen the fixed screw by 60° to 90°, and use a tapering screwdriver to adjust the screw as shown in the figure. Move the bracket (sensor) with the tapering screwdriver little by little, and fix the fixed screw at where the play button's LED (green) is switched to the pause button's LED (orange) (or its reverse).
